DIFFLOCKEDTHE REGISTRY NAMED MODEL · 1998
NAMED MODELMilitary · UKUnited Kingdom

Royal Marines Brigade Patrol Troop WMIK.

A WMIK in Royal Marines hands: the Wolf-based weapons platform in sand finish, with the commander's pintle-mounted GPMG at the front, the gunner's ring at the rear for a .50 HMG, 40 mm GMG or a second GPMG, a side-mounted spare and the stowage of a vehicle living on patrol — as run by 3 Commando Brigade's reconnaissance and brigade patrol troops in Iraq and Afghanistan.

Drive it in the gameSources & evidence
Royal Marines Brigade Patrol Troop WMIK — front three-quarter render
BASE VEHICLEDefender 110CONVERTERRicardo plcIN SERVICE1998OPERATED INUnited KingdomPRODUCTIONUnknownLAYOUT4 wheels · 110″

The record

The WMIK was designed for the army's reconnaissance regiments, but the SAS had pioneered the idea of a Land Rover as a mobile gun platform, and the Royal Marines took to it for the same reason: a commando brigade fighting a long way from its ships needs something faster than a foot patrol and lighter than an armoured vehicle. The Recce Troop of 40 Commando and the Brigade Patrol Troop of 3 Commando Brigade ran WMIKs alongside the Parachute Regiment's Pathfinders, the Royal Irish and the RAF Regiment.

The layout is the standard WMIK. The rear roll-cage carries a well in which the gunner stands, swinging his weapon through a full 360 degrees on a rail — a .50 heavy machine gun, a 40 mm grenade machine gun or a 7.62 mm GPMG — with a Milan anti-tank launcher mountable on the rear bars. The passenger side, normally the commander's station, has a pintle mount that usually carries a GPMG. Underneath is the Wolf TUM HS with its 300 Tdi and 24-volt electrics, with a roll cage lowered to fit a Chinook. The sand finish, side spare and patrol stowage are the marks of Operation Telic and Herrick service, where the Marines' WMIKs saw most of their fighting.

Numbers held by the Royal Marines are not published.

Specification

MANUFACTURERLand Rover
MODIFIER / COACHBUILDERRicardo plc ↗
Engineering Special Vehicles, with Land Rover
MANUFACTUREDWMIK in service from 1998; E-WMIK 2006; R-WMIK 2008
ENGINE2.5 L (2,495 cc) 300 Tdi intercooled turbodiesel inline-four, c. 111 bhp, R380 five-speed gearbox
PRODUCTION RUNUnknown — Royal Marines holdings not published
COUNTRY OF ORIGINUnited Kingdom
OPERATED INUnited Kingdom
STATUSwithdrawn
RECORD KINDNamed model
MODEL LINEDefender
WHEELS4
NOMINAL WHEELBASE110″
CATEGORYMilitary · UK

Catalogue fields describe the vehicle's structure and body as this registry records it. They are not certified factory measurements, and no performance figures are published here.

Sources

  1. 1WMIK — Royal Marines Recce Troop 40 Commando and Brigade Patrol Troop among users; rear well with 360° rail for .50 HMG, 40 mm GMG or GPMG; Milan on the rear roll bars; commander's pintle GPMG; 300 Tdi 111 hp; Macedonia 1999, Sierra Leone, Telic 2003, Afghanistan ↗Elite UK Forces · accessed 2026-09-11SOURCE
  2. 2Land Rover Defender WMIK (Weapons Mounted Installation Kit) — TUM HS base; 300tdi/R380; 24 V; lowered roll cage for Chinook; three-person crew ↗Ex-Military Land Rover Association (EMLRA) · accessed 2026-09-11SOURCE
  3. 3https://www.eliteukforces.info/uksf-gear/wmik/https://www.eliteukforces.info/uksf-gear/wmik/ ↗REFERENCE
