French VTA Helicopter Refueller.

The Véhicule Tactique d'Avitaillement: an open Land Rover carrying TITAN Défense's tactical hot-refuelling dispenser — a 20-metre suction hose on a reel behind the cab, two 40-metre delivery hoses, and filtering, metering and pressure regulation to aviation standard — built to refuel French special forces helicopters away from any airfield. Three were converted in 2010.

Drive it in the gameSources & evidence
French VTA Helicopter Refueller — front three-quarter render
BASE VEHICLEDefender 110CONVERTEROtokar, Titan DéfenseIN SERVICE2010–11OPERATED INFrancePRODUCTION3 vehiclesLAYOUT4 wheels · 110″

The record

Hot refuelling means putting fuel into a helicopter with its rotors still turning, and doing it wherever the aircraft happens to be. That is what the VTA exists for: it carries a complete fuel farm on a Land Rover chassis and drives to the helicopter rather than the other way about.

The base is not a standard Defender. TITAN Défense built the system onto a Core Model chassis cab using Otokar's heavy-duty stretched Defender 130 chassis, giving an overall length of 5,050 mm on the standard 2,150 mm width, and an empty weight of 3,600 kg. The dispenser draws through a single 20-metre suction hose on a reel behind the driver — the vehicle can feed from a bladder, a bowser or a fuel dump — and delivers through two 40-metre hoses, one on the right side and one at the rear. Between the two it filters, meters and pressure-regulates the fuel to aviation safety standards. The equipment is rated from +50 °C down to −25 °C, and a Warn winch provides self-recovery, because the vehicle's whole purpose is to reach places an airfield refueller cannot.

Only three were converted, in 2010, entering service the following year in support of the helicopters of 4e RHFS — the French special forces helicopter regiment. They have proved durable: as of April 2019 all three remained in service, two on constant call with the third held in reserve. The type was shown publicly at Eurosatory in 2012 and 2014 and at SOFINS 2019 at the special forces base near Bordeaux.

Specification

MANUFACTURERTitan Défense ↗
MODIFIER / COACHBUILDEROtokar ↗, Titan Défense ↗
on an Otokar heavy-duty stretched Defender 130 chassis cab
MANUFACTUREDThree vehicles converted in 2010, entering service in 2011
ENGINELand Rover Defender 130 'Core Model' chassis cab driveline — no engine specification published in the sources consulted
PRODUCTION RUN3 vehicles
COUNTRY OF ORIGINFrance / Turkey / United Kingdom
OPERATED INFrance
STATUSin service
OVERALL LENGTH5,050 mm
WIDTH2,150 mm
EMPTY WEIGHT3,600 kg
SUCTION HOSE20 m on a reel behind the driver
DELIVERY HOSES2 × 40 m (right side and rear)
OPERATING TEMPERATURE+50 °C to −25 °C
RECORD KINDNamed model
MODEL LINEDefender
WHEELS4
NOMINAL WHEELBASE110″
CATEGORYMilitary · France

Catalogue fields describe the vehicle's structure and body as this registry records it. They are not certified factory measurements, and no performance figures are published here.

Variants & colours

Factory colours

  • NATO Green (IRR)

Codes on hover. Hex values are representative approximations of period paint unless a source states a measured value.

Sources

  1. 1MLR Pt 19: Véhicule Tactique d'Avitaillement (TITAN Défense Tactical Hot Refuelling Dispenser; Core Model chassis cab on the Otokar stretched heavy-duty D130 chassis; 5,050 mm long, 2,150 mm wide, 3,600 kg empty; 20 m suction hose and two 40 m delivery hoses; filters, meters and pressure-regulates to aviation standards; +50 °C to −25 °C; Warn winch; three converted in 2010, in service the following year with 4e RHFS; all three still serving April 2019; shown at Eurosatory 2012 and 2014 and SOFINS 2019) ↗Joint Forces News · accessed 2026-09-11SOURCE
  2. 2https://www.joint-forces.com/utility-4x4/23174-mlr-pt-19-vehicule-tactique-davitaillementhttps://www.joint-forces.com/utility-4x4/23174-mlr-pt-19-vehicule-tactique-davitaillement ↗REFERENCE
